The Lintec UCP Ultra Concrete Batching Plant delivers high-capacity production with intelligent automation, precision batching, and customizable configurations for large-scale construction projects.
The highly automated Lintec UCP series is the solution for big concrete needs. With models that produce up to 250 cubic metres of ready mix concrete per hour, the UCP series meets the needs of projects requiring thousands of cubic metres a day. At the same time, the UCP ready mix concrete batching plant maintains accuracy in ensuring the quality of concrete.
The UCP series can be customised to suit the requirements of any major project. The twin-shaft mixers, controlled by computerised process control systems running on Windows OS, intensely mixes your concrete in three-dimensional movements.
High production capacities performance, with accurate batching and various concrete mix designs for ready mix and precast applications.
Can be customised to meet project requirements. Control panel for automatic and manual operations with highly efficient computerised process control system.
Equipped with independent or cumulative weighing systems for aggregates batching sequences. Computerised process control systems running on Windows OS.
Can be designed with more than 6 types of aggregates bins with a central-discharge belt conveyor system to the mixers.
Can be designed with 1 mixer with 2 discharge chutes to reduce mixer truck waiting time, thus increasing productivity.
Maintains accuracy in ensuring the quality of concrete with precise batching and mixing control systems.
| Model | UCP120 | UCP160 | UCP200 | UCP240 |
|---|---|---|---|---|
| Rated Output Capacity | 120 m³/hr | 160 m³/hr | 200 m³/hr | 250 m³/hr |
| Mixer Type | Twin-Shaft Mixer | |||
| Output per Batch | 3000 litres | 4000 litres | 4500 litres | 6000 litres |
| Aggregate Batching Sequence | Cumulative | Cumulative | Independent | Independent |
| Cement Weigher | 2000 kg | 2750 kg | 3000 kg | 4000 kg |
| Water Weigher | 750 kg | 1000 kg | 1200 kg | 1500 kg |
| Additive Weigher | 2 x 20 litres | 2 x 20 litres | 2 x 20 litres | 2 x 50 litres |
| Connection Power | 184 kW | 194 kW | 235 kW | 340 kW |
| Generator Set Capacity | 350 kVA | 350 kVA | 500 kVA | 600 kVA |
*Output based on Max 3 aggregates weighing. All specifications are subject to changes without prior notice.
